KEF低音炮Ci200QSB定制嵌入音箱

KEF Ci200QSB 低音嵌入音箱

配合 KEF 专利创新的 Uni-Q 同轴共点单元
Certified to THX ULTRA2 and THX SELECT2 standards, the formidable Ci200QSb-THX in-wall subwoofer delivers deep bass and theatre thumping output capabilities, matched to the uncanny ability to deliver all the drama and emotional intensity of full theatre sound quality.
KEF低音炮Ci200QSB
主要特点
THX Certified Ultra2 / Select2
200mm (8in.) woofer unit with extended bass response
可涂色超薄边饰 (UTB) 和磁性网罩与空间装饰融于一体
安装快捷简便,可以通过狗腿弯孔固定于大多数表面
Can be used in passive mode with internal crossover or active mode with KEF’s KASA500 System Amplifier for THX certified performance
Sold in Pairs
阻抗
6 Ohm - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)

灵敏度
85dB - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)

分频点
100Hz - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)

频率响应
40Hz-100Hz - Passive Mode (Crossover "ON")
18Hz-140Hz - Active Mode (KASA500)

驱动单元
低音: 200mm (8 in.)
建议输出功率
10-150W - Passive Mode (Crossover "ON")
KASA500 - Active Mode (KASA500)
产品外部尺寸
Diameter: 273 x 273 x 106 mm (10.75 x 10.75 x 4.17 in.)

图样尺寸
238 x 238 mm (9.37 x 9.37 in.)

安装厚度
天花厚度(最大):40 毫米(1.58 英寸)
天花厚度(最小):6 毫米(0.24 英寸)

表面安装深度101.6mm (4 in.)

适配框架RIF200S

淨重3.3kg (7.28 lbs)

单位
*以每个计算
